The SN65HVD230QDRG4Q1 is a robust CAN (Controller Area Network) transceiver module designed and manufactured by Texas Instruments. This high-performance integrated circuit is engineered to facilitate reliable communication in automotive and industrial applications, where a dependable data exchange is critical for system performance and safety.

Key Features

• Bus-Fault Protection: The SN65HVD230QDRG4Q1 comes with an exceptional bus-fault protection of up to ±36V, ensuring that the device remains operational even under harsh electrical environments.
• Low Power Consumption: With a current consumption of only 370 μA in the powered-down mode, this transceiver is ideal for energy-sensitive applications.
• Differential Receiver Thresholds: It offers improved noise margin with its differential receiver thresholds that contribute to enhanced signal integrity.
• High Electrostatic Discharge (ESD) Protection: The device is designed with ESD protection exceeding 16 kV HBM (Human Body Model), providing an additional layer of durability and reliability.
• Wide Temperature Range: The transceiver is operational over an industrial temperature range of -40°C to 125°C, making it suitable for extreme operating conditions.

Applications

The SN65HVD230QDRG4Q1 is versatile in its applications, including but not limited to:

• Automotive networks
• Industrial automation systems
• Building automation and control systems
• Medical equipment

Quality and Reliability

As a product of Texas Instruments, the SN65HVD230QDRG4Q1 is manufactured to meet high-quality standards. It is compliant with the automotive industry's stringent AEC-Q100 qualification, ensuring performance and reliability for automotive applications. The device is available in a compact 8-pin SOIC package, which is suitable for space-constrained applications.

Whether you are developing a sophisticated automotive network or a critical industrial control system, the SN65HVD230QDRG4Q1 from Texas Instruments provides a reliable solution for your CAN communication needs.
