LM35DM Real Image LM35DM real image1452 LM35DM real image1453 LM35DM Real Image
LM35DM Real Image LM35DM real image1452 LM35DM real image1453 LM35DM Real Image
Same model may have multiple batches, images only for reference.

LM35DM

Part No LM35DM
Manufacturer Texas Instruments
Catalog Temperature Sensors - Analog and Digital Output
Description SENSOR TEMP ANLG VOLT 8-SOIC / Temp Sensor Analog Serial (2-Wire) 8-Pin SOIC Tube
Datasheet
LM35DM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Sensor Type Analog, Local
Sensing Temperature - Local 0°C to 100°C
Output Type Analog Voltage
Supply Voltage - Operating 4 V to 30 V
Resolution 10mV/°C
Accuracy - Highest (Lowest) ±1.5°C
Testing Conditions 25°C
Temperature Range - Operating 0°C to 100°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 082738-LM35DM
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Defence, Military & Aerospace
Family Name LM35D
Introduction Date September 01, 1997
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LM35DM CAD Model

Description

The LM35DM from Texas Instruments is a precision integrated-circuit temperature sensor that is designed to provide highly accurate, linearly proportional voltage output across a specified temperature range.

  • Temperature Range: -55°C to +150°C
  • Output Voltage: 10mV/°C
  • Supply Voltage: 4V to 30V
  • Self-Heating: Low self-heating capability
  • Package: 8-pin SOIC package
  • Accuracy: ±¼°C @ room temperature and ±¾°C over a full -55 to +150°C temperature range
