LFD182G45DCJD247 Murata Electronics North America
Same model may have multiple batches, images only for reference.

LFD182G45DCJD247

Part No LFD182G45DCJD247
Manufacturer Murata Electronics North America
Catalog RF Multiplexers
Description RF-D
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Multiplexers
Mfr Murata Electronics North America
Series LFD
Package Tape & Reel
Product Status Active
Type Diplexer
Frequency Bands (Low / High) 2.4GHz ~ 2.5GHz / 4.9GHz ~ 5.95GHz
Low Band Attenuation (min / max dB) 30.00dB / -
High Band Attenuation (min / max dB) - / 20.00dB
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric), 8 PC Pad
Base Product Number LFD182
Standard Package 4,000 pcs
MSL Level 1 (Unlimited)
Win Source Part Number 724515-LFD182G45DCJD247
Ultra Librarian 3D Model Ultra Librarian LFD182G45DCJD247 CAD Model

Description

The Murata Electronics North America LFD182G45DCJD247 is a diplexer in the tape and reel package.

  • Series: LFD series
  • Base Product Number: LFD182
  • Applications: designed for RF and wireless applications, specifically for frequency bands ranging from 2.4GHz to 2.5GHz and 4.9GHz to 5.95GHz
  • Low Band Attenuation: 30.00dB
  • High Band Attenuation: 20.00dB
  • Mounting: surface mountable
  • Package: 0603 (1608 Metric), 8 PC Pad package
  • Standard Package: 4,000 pieces
  • Suitability: suitable for high-volume production
  • Status: active product and is currently in production
  • Performance: high-performance diplexer that provides excellent signal filtering and isolation for RF applications
