LTV-354T Real Image LTV-354T real image
LTV-354T Real Image LTV-354T real image
Same model may have multiple batches, images only for reference.

LTV-354T

Part No LTV-354T
Manufacturer Lite-On Inc.
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3.75KV TRANS 4-SOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Lite-On Inc.
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 20% @ 1mA
Maximum DC Current Transfer Ratio 400% @ 1mA
Rise and Fall Time 4μs, 3μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 35V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 200mV
Temperature Range - Operating -30°C to 110°C
Mounting SMD (SMT)
Case / Package 4-SOP (2.54mm)
Win Source Part Number 020729-LTV-354T
Family Name LTV-354T
Introduction Date December 26, 2001
ECCN EAR99
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian LTV-354T CAD Model

Description

The Lite-On Inc. LTV-354T is an isolator with a minimum DC current transfer ratio of 20% @ 1mA and a maximum DC current transfer ratio of 400% @ 1mA. It has a forward voltage of 1.2V and a Vce saturation (Max) of 200mV. The LTV-354T is capable of operating in a temperature range of -30°C to 110°C. It is a 4-SOP (2.54mm) packaged component that has an isolation voltage of 3750Vrms. With a maximum output voltage of 35V and a channel output current of 50mA, this component is ideal for use in isolators.
