20449-001E-03 Taoglas Limited 20449-001E-03 real image
20449-001E-03 Taoglas Limited 20449-001E-03 real image
Same model may have multiple batches, images only for reference.

20449-001E-03

Part No 20449-001E-03
Manufacturer I-Pex
Catalog Coaxial Connectors (RF) - Assemblies
Description MHF 4 RECEPTACLE
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Coaxial Connectors (RF) - Coaxial Connector (RF) Assemblies
Mfr I-PEX
Series MHF4
Package Tape & Reel
Product Status Active
Connector Style IPEX MHF4
Connector Type Receptacle, Male Pin
Contact Termination Solder
Shield Termination Solder
Impedance 50Ohm
Mounting Type Surface Mount
Fastening Type Snap-On
Frequency - Max 6 GHz
Number of Ports 1
Housing Color Black
Center Contact Material Brass
Center Contact Plating Gold
Dielectric Material Liquid Crystal Polymer (LCP)
Temperature Range - Operating -40°C ~ 90°C
Voltage Rating 60 V
Mating Cycles 30
Base Product Number 20449
Standard Package 10,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4010
Win Source Part Number 7403-20449-001E-03
Ultra Librarian 3D Model Ultra Librarian 20449-001E-03 CAD Model

Description

Product Overview

The 20449-001E-03 component is designed for precision and reliability. It caters to high-end applications requiring excellence in performance.

Features and Benefits

  • High precision and accuracy
  • Exceptional reliability in critical applications
  • Wide range of compatibility

Applications

  • Aerospace systems
  • Laboratory equipment
  • Precision instrumentation
  • High-frequency communications
