EL3063 Everlight Electronics Co Ltd EL3063 Real Image
EL3063 Everlight Electronics Co Ltd EL3063 Real Image
Same model may have multiple batches, images only for reference.

EL3063

Part No EL3063
Manufacturer Everlight Electronics Co Ltd
Catalog Optoisolators - Triac, SCR Output
Description OPTOISOLATOR 5KV TRIAC 6DIP / Optoisolator Triac Output 5000Vrms 1 Channel 6-DIP
Datasheet
EL3063 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators - Optoisolators - Triac, SCR Output Optoisolators
Mfr Everlight Electronics Co Ltd
Package Tube
Product Status Active
Output Type Triac
Zero Crossing Circuit Yes
Number of Channels 1
Voltage - Isolation 5000Vrms
Voltage - Off State 600 V
Static dV/dt (Min) 1kV/µs
Current - LED Trigger (Ift) (Max) 5mA
Current - On State (It (RMS)) (Max) 100 mA
Current - Hold (Ih) 280µA (Typ)
Voltage - Forward (Vf) (Typ) 1.5V (Max)
Current - DC Forward (If) (Max) 60 mA
Temperature Range - Operating -55°C ~ 100°C
Mounting Type Through Hole
Package / Case 6-DIP (0.300", 7.62mm)
Supplier Device Package 6-DIP
Approval Agency CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL
Base Product Number EL306
Standard Package 65 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 588547-EL3063
Ultra Librarian 3D Model Ultra Librarian EL3063 CAD Model

Description

The EL3063 is an optoisolator with a triac output.

  • Designed for: applications requiring isolated triac triggering or zero-crossing detection
  • Maximum Forward Current: 60 mA
  • Forward Voltage: 1.5V
  • Off-State Voltage: 600V
  • Maximum On-State Current: 100 mA
  • Channels: single
  • Isolation Voltage: 5000Vrms
  • Features: zero crossing circuit
  • Minimum Static dV/dt: 1kV/μs
  • Package: 6-DIP
  • Mounting: through-hole
  • Operating Temperature Range: -55°C to 100°C
  • Approvals: CSA, DEMKO, FIMKO, NEMKO, SEMKO, and UL
