SN65HVD1781DR Texas Instruments SN65HVD1781DR Real Image SN65HVD1781DR label picture SN65HVD1781DR real image5708 SN65HVD1781DR real image5709 SN65HVD1781DR real image5710 SN65HVD1781DR real image5711 SN65HVD1781DR real image5712 SN65HVD1781DR Real Image1 SN65HVD1781DR Real Image2 SN65HVD1781DR Real Image3 SN65HVD1781DR Real Image4 SN65HVD1781DR Real Image5 SN65HVD1781DR Real Image6 SN65HVD1781DR Real Image7 SN65HVD1781DR Real Image8 SN65HVD1781DR Real Image9 SN65HVD1781DR Real Image10 SN65HVD1781DR Real Image11 SN65HVD1781DR Real Image12
SN65HVD1781DR Texas Instruments SN65HVD1781DR Real Image SN65HVD1781DR label picture SN65HVD1781DR real image5708 SN65HVD1781DR real image5709 SN65HVD1781DR real image5710 SN65HVD1781DR real image5711 SN65HVD1781DR real image5712 SN65HVD1781DR Real Image1 SN65HVD1781DR Real Image2 SN65HVD1781DR Real Image3 SN65HVD1781DR Real Image4 SN65HVD1781DR Real Image5 SN65HVD1781DR Real Image6 SN65HVD1781DR Real Image7 SN65HVD1781DR Real Image8 SN65HVD1781DR Real Image9 SN65HVD1781DR Real Image10 SN65HVD1781DR Real Image11 SN65HVD1781DR Real Image12
Same model may have multiple batches, images only for reference.

SN65HVD1781DR

Part No SN65HVD1781DR
Manufacturer Texas Instruments
Catalog Interface - Drivers, Receivers, Transceivers
Description IC TXRX RS485 FAULT-PROT 8-SOIC
Datasheet
SN65HVD1781DR Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 50mV
Data Rate 1Mbps
Supply Voltage - Operating 3.15 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 029526-SN65HVD1781DR
Family Name SN65HVD1781
Introduction Date January 01, 2008
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN65HVD1781DR CAD Model

Description

The SN65HVD1781DR is a state-of-the-art product from Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • Supply: Single 3.3V
  • Standards: TIA/EIA-485-A and ISO 8482:1987(E)
  • ESD Protection: Exceeding ±16 kV HBM
  • Nodes on Bus: Up to 256
  • Temperature Range: -40°C to 85°C
  • Quiescent Current: 1mA maximum
  • Package: 8-pin SOIC
  • Function: Driver dominant time-out
  • Data Rates: Up to 1 Mbps
  • Slew Rate: Controlled, limits data rate to 250 kbps for low power/EMI
