EL814S1(A)(TU)-V Everlight Electronics Co Ltd
Same model may have multiple batches, images only for reference.

EL814S1(A)(TU)-V

Part No EL814S1(A)(TU)-V
Manufacturer Everlight Electronics Co Ltd
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLTR 5KV TRANSISTOR 4-SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Everlight Electronics Co Ltd
Packaging Reel
Number of Channels 1
Voltage - Isolation 5000Vrms
Current Transfer Ratio (Min) 50% at 1mA
Current Transfer Ratio (Maximum) 150% at 1mA
Rise / Fall Time (Typ) 7μs, 11μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 80V
Voltage - Forward (Vf) (Typ) 1.2V
Current - DC Forward (If) (Maximum) 60mA
Vce Saturation (Maximum) 200mV
Temperature Range - Operating -55°C ~ 110°C
Mounting Style SMD
Manufacturer Package 4-SMD, Gull Wing
Supplier Device Package 4-SMD
Manufacturer Pack Quantity 1,500
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 804975-EL814S1(A)(TU)-V
Ultra Librarian 3D Model Ultra Librarian EL814S1(A)(TU)-V CAD Model

Description

The Everlight Electronics EL814S1(A)(TU)-V is a transistor output optocoupler with a 4-SMD gull wing package. It is manufactured by Everlight Electronics.

  • Voltage Isolation: 5000Vrms
  • Maximum Output Voltage: 80V
  • Operating Temperature: -55°C to 110°C
  • Current Transfer Ratio: 50% @ 1mA
  • Popularity: Medium
  • Packaging: Reel
  • Supply and Demand Status: Balanced
