HCPL-316J-500E

Part No HCPL-316J-500E
Manufacturer Broadcom Limited
Catalog Isolators - Gate Drivers
Description OPTOISO 5KV 2CH GATE DRIVER 16SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Technology Optical Coupling
Number of Channels 2
Isolation Voltage 5000Vrms
Common Mode Transient Immunity (Min) 15kV/μs
Propagation Delay tpLH / tpHL (Max) 500ns, 500ns
Pulse Width Distortion (Max) 300ns
Rise and Fall Time 100ns, 100ns
Current - Output High, Low 2A, 2A
Current - Peak Output 2.5A
Supply Voltage - Operating 15 V to 30 V
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 16-SO
Approvals CSA, IEC/EN/DIN, UR
Win Source Part Number 016873-HCPL-316J-500E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name HCPL-316J
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Philippines, Thailand
Halogen Free Compliant
Estimated EOL Date 2023
Quantity per package 850
Ultra Librarian 3D Model Ultra Librarian HCPL-316J-500E CAD Model

Description

The HCPL-316J-500E is a two-channel, 2A/2A output current high-speed optocoupler. It is designed for high-speed communication applications and provides high-speed performance with low power consumption.

  • Common-Mode Transient Immunity: 15kV/μs
  • Propagation Delay: 500ns
  • Pulse Width Distortion: 300ns
  • Isolation Voltage: 5000Vrms
  • Package: 16-SO
  • Operating Temperature: -40°C to 100°C
  • Popularity: High
  • Estimated EOL Date: 2023
  • Halogen-Free: Compliant
  • Manufacturing Location: Philippines and Thailand
