CPDUR5V0CSP-HF Comchip Technology
Same model may have multiple batches, images only for reference.

CPDUR5V0CSP-HF

Part No CPDUR5V0CSP-HF
Manufacturer Comchip Technology
Catalog TVS - Diodes
Description TVS DIODE 5VWM 20VC 0603/SOD523F
Datasheet
CPDUR5V0CSP-HF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Comchip Technology
Package Tape & Reel
Product Status Active
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 5V (Max)
Voltage - Breakdown (Min) 6V
Voltage - Clamping (Max) @ Ipp 20V
Current - Peak Pulse (10/1000µs) 3A
Power - Peak Pulse 60W
Power Line Protection No
Applications General Purpose
Capacitance @ Frequency 0.4pF @ 1MHz
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case 2-SMD, No Lead
Supplier Device Package 0603/SOD-523F
Standard Package 4,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 580217-CPDUR5V0CSP-HF
Ultra Librarian 3D Model Ultra Librarian CPDUR5V0CSP-HF CAD Model

Description

The 580217-CPDUR5V0CSP-HF is a TVS diode designed for circuit protection against transient voltage spikes.

  • Diode Type: bidirectional zener
  • Reverse Standoff Voltage: 5V
  • Breakdown Voltage: 6V
  • Clamping Voltage @ Peak Pulse Current: 20V @ 3A
  • Power Rating: 60W
  • Capacitance: 0.4pF @ 1MHz
  • Application Field: general purpose applications
  • Package: 2-SMD, no lead
  • Manufacturer: Comchip Technology
